Pylex 50 in Adjustable Helical Pile – Fast, Reliable Support Without Concrete
MSRP
55,00$
Find Pylex Products at a Home Depot Location Near You
The Home Depot — Cadillac, MI
The Home Depot — Gaylord, MI
The Home Depot — Alpena, MI
Description
- Strong Support: Holds up to 5,000 lbs in sand, 3,500 lbs in clay
- Frost-Safe: 42 in depth goes below the frost line
- Adjustable: Saddle height adjusts up to 3 in
- Expandable: Add a 24 in extension (Pylex #10571)
- Durable Finish: Rust-resistant baked powder coating
BEFORE INSTALLING THIS PRODUCT: BE SURE TO COMPLY WITH ALL BUILDING CODES IN EFFECT IN YOUR AREA
Features
- Material Steel
- Height 50 in
- Tube diameter 1-¼ in
- Diameter of helical disc 6 in
- Color Black
- Product reference 10555
Also available online
Product
Is there a way to go deeper with the product?
Yes. We offer a 24 in extension to help you reach your local frost line. (Pylex product # 10571)
Installation
What if I hit a rock during installation?
To avoid this, we suggest using a ½ in steel rod to check for rocks or roots and act as a guide during installation.
Installation
How is this product installed?
By using an 8-foot-long 2x4 as a lever. If the soil is not well compacted to a depth of 4 feet, it is important to add a 24 in extension. (Pylex product # 10571)
Our installation video will teach you how to properly compact the soil.
Installation
Is there a faster way to install the product?
Yes. You can install it in under 2 min with a 1 in socket impact wrench with 1000 ft-lbs of torque and our installation adapter. (Pylex product # 10540)
Installation
How much space is required between each pile?
For a porch, we recommend one pile every 8 ft. For load-bearing walls with a roof, one pile every 4 ft.
Installation
How can I prevent the helical pile from moving sideways in the ground?
By adding a Pylex Stabilizer. (Pylex product # 10575). Driving the helical pile into the ground may disturb the surrounding soil, but after a few rains, the soil naturally compacts again.
Compatibility
Can I use this product with a 6x6 post?
Yes, the Pylex 50" can be used with a 6x6 post by combining it with the saddle of the Adjustable Deck Support 66 (Pylex product # 12097) or the head of the Adjustable Extendable Deck Support 33-66 (Pylex product # 12098).
